Allen & Heath Qu-16 22x12 Digital Mixer

The Qu-16 combines exceptional functionality with innovative design to deliver a professional mixing experience with class-leading sound quality. Suitable for Live, Studio Streaming, A/V Install, Corporate Audio, Houses of Worship and more.

Key Features:

• 19” Rack Mountable
• 16 Mono Mic/Line Inputs (TRS + XLR)
• Recallable AnaLOGIQTM Preamps
• 3 Stereo Inputs (TRS)
• 12 Mix Outputs (XLR)
• 7 Monitor Mixes (4 mono + 3 stereo)
• 4 FX Engines
• 2 dedicated FX Sends / Returns
• 4 Mute Groups
• 4 DCA Groups
• AES Digital Out
• 24×22 USB Audio Interface
• dSNAKETM Remote Audio Port
• 17 Motor Faders
• 800×480 Touchscreen
• 4 Soft Keys
• Trim, polarity, HPF, gate, insert, 4-band PEQ, compressor, delay on all Inputs
• Insert, 4-band PEQ, 1/3 octave GEQ, compressor, delay on all Outputs
• Automatic Mic Mixer
• Channel Ducker on all Inputs
• ProFactory Mic Presets
• RackFX Library
• Built-in Signal Generator
• RTA with Peak Band indication
• Spectrogram to aid feedback elimination and room acoustics
• Qu-Drive Direct Multitrack Recording / Playback on USB drives
• DAW MIDI Control
• Compatible with Qu-Pad iPad App, Qu-You iPhone / Android personal monitoring app, Qu-Control customisable iOS app for simple wireless control
• Compatible with ME Personal Mixing System
