HK Audio LINEAR 9 210 LTA 2x10-inch Active PA Subwoofer

The LINEAR 9 210 LTA convinces with its enormous throw and power. It comes into its own particularly in confined venues that require a long throw. In addition, the LINEAR 210 LTA allows flexible sound coverage thanks to the option of using it in a cluster.

As a pure mid/high unit, equipped with a rotating 60° x 25° horn with a powerful 1.4“ driver and two vertically arranged 10“ speakers, it achieves outstanding efficiency.

The MCT developed by HK Audio converts the point source of the compression driver into a line source which, in addition to razor-sharp dispersion, enables optimum coupling of further LINEAR 9 210 LTA speakers. The multicell MCT achieves significantly better distortion performance compared to conventional horns of the same size.

The robust birch multiplex enclosure with resistant PU coating protects the LINEAR 9 210 LTA not only from wind and the elements but also during transport from the storage to the venue and back again. All LINEAR 9 models are manufactured in Germany.

Features:

• Scalable mid/high unit with long throw and network control
• 2 × 10-inch bass-midrange driver with 2.5-inch voice coil
• 1 × 1.4-inch compression driver with 2.5-inch voice coil
• Rotatable MCT horn, 60° × 25° (horizontal × vertical)
• DSP platform with fully parametric 10-band EQ, delay and limiting for un- compromised individual adjustment
• Modern network technology for precise control of all DSP features
• Additional DSP-Out with the full range of features for integration of non- network-compatible loudspeakers
• Direct access to easily selectable presets on the speaker for use in a single application, or as a cluster of two or three
• High-resolution AD/DA converters with 96 kHz, FIR filtering and low latency of less than 2.6ms
• The cabinet design allows horizontal clusters to be formed quickly and easily
• DuoTilt for 3° or 7° tilt for tripod mounting
• User friendly rigging and mounting options
• Professional, lockable PowerCon and EtherCon connections
• Sturdy enclosure made of birch multiplex with PU coating
• Made in Germany
